They use a rotating spiral structure to continuously push materials from one location to another. They are specifically designed for particles,Powder, ultra-fine powder and other materials are designed and manufactured. It is mainly composed of driving screw, conveying pipe, power mechanism and so on.Theyt can also be customized to produce cone-shaped, side-by-side and other non-standard screw conveyors, or other specifications Screw conveyor equipment.
Specifications
| Feeding conveyor | Horizontal conveyor | |||||||
| device ID | ASC-F1 | BSL-F3 | BSL-F5 | BSL-F8 | ASC-H1 | ASC-H3 | ASC-H5 | ASC-H8 |
| Angle of Elevation | 45°(Standard) Or customized | 0°(Standard) Or customized | ||||||
| Spiral Speed | 140rmp | |||||||
| Diameter of Pipe | φ89 | φ114 | φ141 | φ168 | φ89 | φ114 | φ141 | φ168 |
| Capacity | ≈1m³/H | ≈3m³/H | ≈5m³/H | ≈8m³/H | ≈1m³/H | ≈3m³/H | ≈5m³/H | ≈8m³/H |
| Power Supply | 380V 50-60Hz | |||||||
| Hopper Volume | 110L（Standard） | 230L（Standard） | 230L（Standard） | Customize | ||||
Pictures
